The Ambu RIPmate Kit w/ Disposable Bands - STD (#819200-100) includes two RIP locks, two processors, and one roll band.

Warranty: 1 Year - processors, belts, and cables.

Designed to measure inductance changes in the wire of the belt as it expands and contracts with breathing, the Ambu RIPmate Kit w/ Disposable Bands - STD eliminates false paradoxical signals and the potential of signal loss due to lost belt tension. That data is both qualitative and quantitative when calibrated with a spirometer.

Features

Ambu RIPmate Kit w/ Disposable Bands - STD Features

• Made from soft and flexible materials for a comfortable fit.
• Cut to length for a perfect fit.
• No adjusting necessary - grips the patient tight and prevents loss of signal due to belt slipping.
• Buckles designed with rounded corners and flat profiles for additional comfort.
• Eliminates the need to clean the belt between uses.
• Provides the same quality signal as RIPmate reusable belts.

Specifications

Ambu RIPmate Kit w/ Disposable Bands - STD Specifications

• Lead Wire: Two conductors, approximately 205 cm.
• Terminators: 1.5 mm safety pins (custom terminators available).
• Belting Systems: Disposable, cut to length.
• Low Frequency filter/time constant: 0.16 Hz (or 1 second longer). Shorter time constants or higher low frequency filter settings will significantly attenuate waveforms.
• High Frequency Filter: 8-15 Hz.
• Sensitivity: Adjustment of the sensitivity up or down is typically required. Response is dependent upon such variables as sensor application and patient effort.
• Width: 1 inch.

Accessories

Ambu RIPmate Kit w/ Disposable Bands - STD Accessories

• RIPmate Inductance Kit.
• RIPmate Inductance Pediatric Kit (#819102-100).
• RIPmate Inductance Infant Kit (#819101-100).
• RIPmate Adult Inductance Alice 5 Kit (#819100-121).
• QDC Viasys SUM RIP Bet Kit (#819100-100).
• RIPmate Kit w/ Disposable Bands - Keyhole (#819200-108).
• RIPmate Kit w/ Disposable Bands - A5 (#819200-121).
• RIPmante Single Use Belt Roll (#819201-000).
• RIPmate Locks (#819211-000).

Literature

Ambu RIPmate Kit w/ Disposable Bands - STD Literature

Ambu Neurodiagnostic Supplies Catalog

Ambu RIPmate Kit With Dispoable Bands Datasheet

Ambu Sleepmate Catalog
